Interface

5 x 10/100/1000Base-T RJ45 ports (Data)

1 x 1000Base-X Fibre port (Data)

Ethernet

10/100/1000BaseT(X) auto-detect,full/half-duplex MDI/MDI-X adaptive

Fiber Port

Optional optical module versions: 1 x 9 module or SFP module

Network Protocol

IEEE802.3 10BASE-T

IEEE802.3i 10Base-T

IEEE802.3u 100Base-T X

IEEE802.3ab 1000Base-T

EEE802.3z 1000Base-X

IEEE802.3x

Forwarding Mode

Store-and-forward (full wire speed)

Backplane Bandwidth

12Gbps (non-blocking)

Packet Forward Speed

8.92Mpps

Packet Buffer

2. 1M

Transmission Distance

10BASE-T: Cat3,4,5 UTP (≤100 metres)

100BASE-TX: Cat5 or later UTP(≤100 meter)

1000BASE-T: Cat5e and above UTP (≤100m)

Multi-mode Operating wavelength: 850nm , transmission   distance:0~500 m

Single-mode Operating wavelength: 1310nm, transmission   distance:0~40km;Operating wavelength: 1550nm,transmission distance:0~120km

LED Indicator

Power indicator: PWR

Interface indicators: Electrical port, Optical port (Link indicator)

Power Supply

Input voltage: DC 9~57V

Power interfaces: 1x DC5521 jack, and 2x V+/V-   redundant DC pow er inputs (4-pin Phoenix connector)

Redundant power design with reverse-polarity protection

Power Consumption

No-load power consumption:1. 1W

full-load power consumption:3.34W

Mechanical properties

Enclosure: IP40 protection rating, aluminium alloy housing

Cooling method: Natural cooling, fanless

Dimensions: 116x85x33 mm

Weight: 0.31 kg

Mounting options: Desktop, 35 mm DIN rail mounting

Working Environment

Operating temperature: -40 to 85°C (-40 to 185°F)

Storage temperature: -40 to 85°C (-40 to 185°F)

Relative humidity: 5% to 95% (non-condensing)

Industry Standard

IEC 61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge

IEC 61000-4-3 (RS): 10V/m (80~ 1000MHz)

IEC 61000-4-4 (EFT): Power line: ±4kV; Data   line: ±2kV

IEC 61000-4-5 (Surge): Power line:CM ±4kV/DM ±2kV;Data line:   ±4kV IEC   61000-4-6 (Radio Frequency Conducted):10V( 150kHz to 80 MHz) IEC 61000-4-8   (Power Frequency Magnetic Field):100A/m continuous; 1000 A/m, 1 s to 3 s

IEC 61000-4-9 (Pulsed Magnetic Field): 1000 A/m

IEC 61000-4-10 (Damped Oscillatory Field): 30 A/m at 1   MHz IEC 61000-4-12/ 18 (Surge Wave): CM 2.5 kV, DM 1 kV

IEC 61000-4-16 (Common-Mode Conducted):30V   continuous;300V, 1s

FCC Part 15/CISPR22 (EN55022): Class B  IEC61000-6-2 (General Industrial Standards)

IEC60068-2-6 (Vibration Resistance)

IEC60068-2-27 (Shock Resistance)

IEC60068-2-32 (Free Fall)

Warranty

5 years for the whole machine (excluding   accessories)
