Industrial Cellular Router Comparison

The main difference and comparision among WLINK series Industrial Cellular Router.

Overview
Specification
Order Model
Documentation

WLINK Industrial 5G Router Comparison

Specfication	G955	G535	G525	G930	G530	G230
Wlink OS	Default	Default	Default	Default	Default	Default
OpenWrt OS	Optional	Optional	Optional	Optional	Optional	Optional
Optional Network Type	5G SA/NSA 4G Cat4/6/12/20 3G 2G	5G SA/NSA 4G Cat4/6/12/20 3G 2G	5G SA/NSA 4G Cat4/6/12/20 3G 2G	5G SA/NSA 4G Cat4/6/12/20 3G 2G	5G SA/NSA 4G Cat4/6/12/20 3G 2G	5G SA/NSA 4G Cat4/6/12/20 3G 2G
Ethernet Port	1000M	1000M	1000M	1000M	1000M	1000M
WiFi	802.11 b/g/n 802.11 ax	802.11b/g/n 802.11ax	802.11 b/g/n 802.11 ax	802.11 b/g/n 802.11 ac	802.11 b/g/n 802.11 ac	802.11 b/g/n 802.11 ac
WiFi Speed	3Gbps	1.8Gbps	3Gbps	1.2Gbps	867Mbps	867Mbps
VPN	PPTP/L2TP/GRE/OpenVPN/DMVPN/IPSec(IKEv1/IKEv2)
Interface	5xGbE 1x RS-232 1x RS-485 3x I/O 1x USB	4xGbE 1x RS-232 1x RS-485 2x I/O	5xGbE 1x RS232/RS485	5xGbE 1x RS-232 1x RS-485 3x I/O 1x USB	4x GbE 1x RS232 1xRS485 4x I/O	2x GbE 1x RS232
SIM Slot	One	Two	One / Two	Two	Two	One
Avtive PoE	-	-	-	-	Optional	-
Dimension (mm)	190 x 124 x 60	142 x 108 x 48	150 x 102 x 24.5	179 x 124 x 43	132x 112 x 44	103x 73.5 x 28
Unit Weight	1080g	750g	420g	610g	400g	320g
Mount Type	Desktop Wall Mount	Desktop Wall Mount DIN Rail Mount	Desktop Wall Mount	Desktop Wall Mount	Desktop Wall Mount DIN Rail Mount	Desktop Wall Mount DIN Rail Mount
GNSS	Optional
Power Supply(VDC	7.5 - 32/48	7.5 - 32/48	7.5 - 32/60	7.5 - 32/48	7.5 - 32/48	7.5 - 32/48
Operation Temperature	- 30 ~ 70 degree
Storage Temperature	- 40 ~ 85 degree
Relative Humidity	<95% (non-condensing)

WLINK Industrial 4G Router Comparison

Specfication	G200	G510	G520	R130	R230	R100	R200	R520	R210	ER120	R220
Wlink OS	Default	Default	Default	Default	Default	Default	Default	Default	Default	Default	/
OpenWrt	/	/	/	Optional	Optional	Optional	Optional	Optional	Optional	Optional	Default
Network Type	4G/3G/2G	4G/3G 2G	4G/3G 2G	4G/3G 2G	4G/3G 2G	4G/3G 2G	4G/3G 2G	4G/3G 2G	4G/3G 2G	4G/3G 2G	4G/3G 2G
WiFi Standard	n/ac	n/ac	n/ac	b/g/n	b/g/n	-	b/g/n	b/g/n	b/g/n	b/g/n	b/g/n
WiFi Speed	867Mbps	867Mbps	867Mbps	150Mbps	300Mbps	-	150Mbps	150Mbps	150/300Mbps	150/300Mbps	300Mbps
Ethernet Speed	1000M	1000M	1000M	10/100M	10/100M	10/100M	10/100M	10/100M	10/100M	10/100M	10/100M
Interface	2x GbE 1xRS232/485	4xGbE 1x RS232 3x I/O	5x GbE 1x RS232/485	1xLAN 1x RS232 1x RS485	2x LAN 1x LAN/WAN 1x RS232 1x RS485 2xI/O 1x USB	1x LAN 1x RS232/RS485	1x LAN 1x WAN/LAN	4x LAN 1x WAN/LAN 1x RS232	1x LAN 1x WAN/LAN 1x RS232 3x I/O 1x Console	1x LAN 1x WAN/LAN 1xRS232/TTL 2x I/O	2x LAN 1x WAN 1x RS232/485 3x I/O
SIM Slot	One	Two	One / Two	Two	Two	One	One	One / Two	Two	One	Two
Avtive PoE	-	-	-	-	-	-	-	Optional	-	-	-
Dimension (mm)	103x73.5x25.5	132x112x44	150x102x25.5	103x 73.5x 25.5	102x100x 42	78.5x59x23.5	103x73.5x25.5	150x102x25	102x100x42	58x38x10.8	102x100x42
Unit Weight	320g	400g	410g	225g	350g	130g	300g	400g	300g	23g	350g
Storage	Optional	Optional	Optional	-	Optional	-	-	Optional	Optional	-	Optional
Mount Type	Desktop Wall Mount DIN Rail Mount	Desktop Wall Mount DIN Rail Mount	Desktop Wall Mount	Desktop Wall Mount	Desktop Wall Mount	Desktop Wall Mount	Desktop Wall Mount	Desktop Wall Mount	Desktop Wall Mount DIN Rail Mount	Embedable	Desktop Wall Mount DIN Rail Mount
VPN	PPTP/L2TP/GRE/OpenVPN/Wireguard/Zerotier/DMVPN/IPSec(IKEv1/IKEv2)										N/A
GNSS/GPS	Optional
Power Supply (VDC)	7.5 - 32/48	7.5 - 32/48	7.5 - 32/48	7.5 - 32/48	7.5 - 32/60	7.5 - 32/48	7.5 - 32/48	7.5 - 32/60	7.5 - 32/48	7.5 - 32/48	7.5 - 32/48
Operation Temperature	- 30 ~ +75℃
Storage Temperature	- 40 ~ 85℃
Relative Humidity	<95% (non-condensing)
